Sack Discharging Dump Station Automatic Bag Opener

Place of Origin : China

Brand Name : JL

Packaging Details : PLYWOOD BOX

Supply Ability : 100 Set/Sets per Month

Price : $12,000.00 - $23,000.00/Pieces

Type : Filling Machine

Applicable Industries : Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Food & Beverage Shops

Showroom Location : None

Condition : New, New

Application : Food, Commodity, Chemical

Packaging Type : other

Packaging Material : other

Automatic Grade : Automatic

Driven Type : Electric, Electric

Voltage : 380v

Warranty : 1 Year

Key Selling Points : Easy to Operate

Machinery Capacity : -

Filling Material : other

Marketing Type : Hot Product 2019

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : other

Product name : 20-50kg bag slitting machine

Capacity : 100 to 800 bags/hour of 25 to 50 kg.

Type of bags : Except Jute made, all other material bags

Material Retention : 2% maximum

Machine Specification(Weight ) : 50Kgs/bag

Particle sizes : Powder & pellets of free flow characteristics.

After Warranty Service : Video technical support, Spare parts, Field maintenance and repair service

Local Service Location : None

After-sales Service Provided : Online support, Video technical support

Port : shanghai

Contact Now

Sack Discharging Dump Station Automatic Bag Opener

25-50kg automatic bag slitting machine, bag slitting system,automatic bag emptying machine

Working principle:

Automatic bag slitting machine is mainly composed of belt conveyor and main machine. The main machine is composed of base, cutter box, drum screen, screw conveyor, waste bag collector and dust removal device.

The bagged materials are transported to the slide plate by the belt conveyor, and slide along the slide plate by gravity. During the sliding process, the packaging bag is cut by fast rotating blades, and the cut residual bags and materials slide into the drum screen for screening. The materials dropped from the drum screen are output by screw conveyor, and the damaged packaging bags, impurities and caking materials are taken out of the body by the drum screen. The dust caused in the process of cutting knife breaking bag is collected by bag filter and shaken into screw conveyor through pulse control system (the materials output from screw conveyor can be transported to material storage tank by pipe chain conveyor or pneumatic conveying device).

Technical Specification:

MoC	Available in mild steel construction with optional coatings & stainless steel with optional finishes
Capacity	100 to 800 bags/hour of 25 to 50 kg
Type of bags	Except Jute made, all other material bags
Material Retension	2% maximum
Bag size	up to 700mm400mm145mm (weight-50kg/bag)
Emptying efficiency	98%– 99% depending on flowing characteristics of the material
Particle size	Powder & pellets of free flow characteristics

Sack Discharging Dump Station Automatic Bag Opener

Company Information

Sack Discharging Dump Station Automatic Bag Opener

Wuxi Jianlong Packaging Co., Ltd.

Wuxi Jianlong Packaging Co., Ltd. is a R & D and production enterprise specializing in solid material packaging solution. Our product portfolio includes bagging scales and feeders, open mouth bagging machines, valve bag fillers, jumbo bag filling machine, automatic packing palletizing plant, vacuum packaging equipment, robotic and conventional palletizers, stretch wrappers, conveyors,telescopic chute, flow meters, etc. Wuxi Jianlong has a group of engineers with strong technical strength and rich practical experience, which can help customers with one-stop service from solution design to product delivery, freeing workers from the heavy or unfriendly working environment, improving production efficiency, and will also create considerable economic returns for customers.
